Description
The Motobilt Jeep JK Hatchet Rear Frame Chop Bumper allows for 5 inches of additional ground clearance over the factory receiver hitch. The additional ground clearance you gain is the same as going from a 35 inch tire to a 40 inch.
Fits:
Jeep JK & JKU Wrangler 2007 to 2018
Specifications
- 3/16 inch Laser cut and CNC bent steel body
- 3/4 inch Thick laser cut D-Rings that pass through the bumper and welded inside and out
- Gain 2 3/8 inches up and 3 3/8 inches back of ground clearance
- 5 inches of additional clearance over the factory receiver hitch
- Ultra tight design allows the use of a large spare tire
- Full protection from corner to corner
- Includes high strength cross member
- Cross member bolts into factory body mounts then must be welded to the frame
- Works with factory frame or Motobilt jeep JK back half kit
- Cross member includes pre-installed threaded inserts for mounting Motobilt Hatchet JK frame chop rear bumper
- Threaded mounting holes for JK rear fuel cell skid plate also included
-
Ships raw steel. Must be painted or powder coated to prevent rust. See (Steel-It)
- Installation video can be found under the Instructions tab
- Includes necessary hardware
- Weight: 80lbs (approx.)
Notes:
- Requires cutting of rear frame rails and removal of factory rear cross member
- Cross member must be welded to frame rails.
- A receiver hitch will NOT work with this bumper.
Product Components
Instructions
Installation Instructions
