Description
The Model C created the modern standard in 24” BMX
With its proven 20” inspired geometry, this bike can be ridden with a greater sense of control at full speed. Bigger riders will notice its advantages right away. It comes with an awesome Odyssey/Sunday parts package at an affordable price
When it comes to 24”, the Model C changed the game
Key Features
24″ Pro-Style Geometry
Odyssey Broc Raiford Grips
Odyssey Springfield Brakes
Odyssey Twisted PC Pro Pedals
Sunday Badge Pivotal Seat
FSA Conical Headset
Odyssey Stage 1 Rims
Odyssey Path Pro OEM Tires
Sealed Front & Rear Hubs
Specifications
Frame: Model-C 24×22″, Hi-Ten Steel w/ Integrated HT, Cr-Mo DT/CS
Fork: Sunday Model-C, 24″ fork w/ 2-piece chromoly steerer tube and welded pre-load
Handlebar: Sunday 24umph XL OEM, 2-piece
Stem: Sunday Freeze top load, 48mm
Headset: FSA integrated conical, 1-1/8″
Alloy Cap: Sunday M16, aluminum
Brake Lever: Odyssey Springfield
Brakes: Odyssey Springfield U-brake
Brake Cable: Odyssey Quik Slic
Grips: Odyssey Broc Raiford
Seat: Sunday Badge, Pivotal
Seat post: Sunday Pivotal, 300mm
Seat Clamp: Sunday, Quick Release
Sprocket: Sunday Sabertooth v2, 25T, steel
Cranks: 175mm, 3-piece, chromoly
BB Parts: Sealed, Mid, 19mm
Pedals: Odyssey Twisted PC Pro
Rims: Odyssey Stage 1, 24″, 36H
Front Hub: Sunday, 36H, low-flange, sealed , 3/8″ axle
Rear Hub: Sunday 36H, sealed, 14mm axle w/ 10T Driver
Spokes: 14g steel, black
Tires: Odyssey Pursuit OEM, 24 x 2.2″ (F & R)
Chain: KMC Z1 wide
Frame Geometry
Top Tube Length: 22″
Head Tube Angle: 74.5°
Seat Tube Angle: 71°
Chainstay Length: 14.6-14.85”
Bottom Bracket Height: 13.75″
Standover: 9.25”
Handlebar Geometry
Rise: 7.75″
Width: 28″
Backsweep: 12°
Upsweep: 4°
Weight
With Brakes: 29.1lbs
*Specs subject to change without notice
